Procon-series
Customized Switches Unit, Designed for Multiple Control Purposes, Illuminated Full or around the Rim
Welcome to talk to our engineers for your individual requirement.
The Control Unit can be built with tact switches lighted or unlighted, power switches or encoders.
Cable and wire harness assembly can be connected to the unit for your quick installment.
加入詢問
Customized Switches Unit, Designed for Multiple Control Purposes, Illuminated Full or around the Rim
Welcome to talk to our engineers for your individual requirement.
The Control Unit can be built with tact switches lighted or unlighted, power switches or encoders.
Cable and wire harness assembly can be connected to the unit for your quick installment.
Feature
- Rating: 12VDC, 50mA (SPST)
- Initial contact resistance : 100m Ohm max.
- Insulation resistance : 100M min
- Dielectric strength : 250 VAC for 1 minute
- Temperature range : -10 to +60 degrees in celsius
- Operating force: 180gf +/- 30
- Switch life: 100,000 cycles minimum
- Cap: ABS
- Terminals: Brass, silver or tin plated
- Frame:Nylon66,UL rated:94V-2 min
Item
Design Example:
|
Control Handle for Appliance
|
Two Round Push Switches with LED illuminated |
