- Rating: 3.0Amp - 25.0Amp
- Input power: 125/250Vac, 50Vdc, 50/60Hz
- Interrupt capacity: 1000Amp, 125Vac
- Dielectric strength: 1500Vac, 1 minute
- Resettable overload capacity: 10 times rated current
- Voltage drop: less than 0.25V
- Insulation resistance: 500 M. ohms
- Reset time: within 60 seconds
|
- Temperature rise: less than 65 degrees in Celsius, at 100% of rated current applied continuously at 25 degree in Celsius
- Calibration (at 25 degree)
- 100% of rated current: hold, no-trip
- 135% of rated current: trip in 1 hour
- 200% of rated current: 4-25 seconds trip
- 300% od rated current: 1.6-4.8 seconds trip
|
